Description
SilverStone Sugo 14 Cabinet (White)
Features :
- Supports 3 slot full length graphics cards with adjustable graphics card holder
- Compatible with Mini-DTX / Mini-ITX motherboard & ATX PSU
- Supports up to 240mm radiators
- Modular design with 4 removable panels (top, left, right, bottom)
- Different configurations support various storage components for 5.25", 3.5" and 2.5"
- Front I/O port includes: USB 3.0 x 2, USB 2.0 x 1, combo audio x 1
High compatibility with no compromise
Unlike most SFF Mini-ITX chassis on the market, SUGO 14 is capable of fitting a 3 slot full length graphics cards on the left side and up to 240mm radiators on the right side.
Exceptional usability & upgradability
Modular design allows for removal of 4 panels which eases the build process and ease of upgradability at a later date.
Substantial compatibility beyond expectations
SUGO 14’s chassis supports 3 x 2.5" SSDs, and its multi-purpose bracket allows for different configurations to support various cooling and storage components
2-way placement
SUGO 14 comes included with 8 foot pads, the design allows users the flexibility in choosing how they wish to place their chassis
Thoughtful design down to the details
- GPU holder
- M.2 cutout
- CPU cooler cutout
- ATX PSU support
Specifications :
Model No. | SST-SG14W (white) |
Material | Plastic front panel, steel body |
Motherboard | Mini-DTX, Mini-ITX |
Drive bay | External 5.25" x 1 (without radiator and 3.5" x 1 installed) |
Internal "3.5"" x 2 (without radiator and 5.25"" installed) 2.5"" x 3" |
|
Cooling system | Front N/A |
Rear 120mm / 140mm x 1 (120mm black fan x 1 included) | |
Side 120mm / 140mm x 2 | |
Top N/A | |
Bottom N/A | |
Internal N/A | |
Radiator support | Front N/A |
Rear 120mm | |
Side 120mm / 240mm | |
Bottom N/A | |
Internal N/A | |
Expansion slot | 3 |
Front I/O port |
USB 3.0 x 2 USB 2.0 x 1 Combo audio x 1 |
Power supply | Standard PS2(ATX) |
Limitation of VGA card |
Length: 330mm Width: 148mm |
Limitation of CPU cooler |
Air cooler: 182mm (without top fan) 240mm AIO water block: 55mm |
Limitation of PSU | 150mm |
Net weight | 4.89 kg |
Dimension |
247mm (W) x 215mm (H) x 368.1mm (D), 19.55 liters 9.72" (W) x 8.46" (H) x 14.49" (D), 19.55 liters |
Warranty | 1 Year |
Note | *** Features, Price, Specifications are subject to change without notice. |
