- NZXT C750 750W Bronze Non-Modular ATX Power Supply Unit
Description
Features:
- Up to 88% efficiency at 50% load exceeds 80 Plus Bronze standards, reducing energy waste and heat.
- A 120mm fluid dynamic bearing fan delivers low-noise performance with enhanced longevity.
- DC-to-DC conversion ensures consistent power delivery to GPUs up to 220W, such as the RTX 3070.
- Tested for safety at up to 40°C, and features over-temperature and over-current protections.
- Main PSU cables are nylon-sleeved for durability with a matte black finish to match any build.
Specifications:
| Model Number | PA-7B2BB-UK |
| OUTPUT CONNECTOR(S) |
24-pin ATX Power: 1 4+4-pin CPU power: 2 6+2-pin PCIe power: 2 SATA Power: 4 Peripherals: 4 |
| CABLE SPECS |
24-pin ATX power: 600mm, Nylon sleeving 4+4-pin CPU power: 700mm, Nylon sleeving 6+2-pin PCIe power: 650 + 150mm, Nylon sleeving SATA power: 500 + 150 mm Peripherals: 500 + 150 mm |
| AC INPUT RATING | 100 - 240Vac: 10A-5A 50Hz-60Hz |
| DC OUTPUT RATING | #ERROR! |
| OPERATION |
PF Correction: Active@0.96 MTBF: 100,000 hours Operation Temperature: 0 to 40°C |
| ENERGY EFFICIENCY |
Rating: 80 Plus Bronze 10% loading: 86.2% @115Vac 20% loading: 88.97% @115Vac 50% loading: 88.7% @115Vac 100% loading: 83.2% @115Vac |
| FAN SPECS |
Dimensions: 120 x 120 x 25 (mm) Speed: 2400 ±10% RPM Airflow: 64.4 CFM (Tpy.) Noise: 39.92 dBA max Bearing: FDB (Fluid Dynamic Bearing) |
| GENERAL |
Dimensions (W x L x H): 150 x 140 x 86mm Material(s): Steel, PCB and Plastic Compliance Standard: ATX12V v2.53 / EPS12V v2.92 Regulation & Certification: FCC, Canada, CE, CB(IEC 62368-1), BIS, UKCA, CCC, BSMI, Mexico NOM Hazardous Materials: Taiwan and China RoHS Table, CP65, EU REACH Protections: OVP (Over Voltage Protection) UVP (Under Voltage Protection) SCP (Short Circuit Protection) OTP (Over Temperature Protection) OPP (Over Power Protection) OCP (Over Current Protection) |
| Warranty | 3 years |
| Note* | Price, feature and specifications are subject to change without notice. |
